AFM20-F02-D
Product number:
AFM20-F02-D
Product information "AFM20-F02-D"
• ISO 8573-1:2010 compliant
• Nominal filtration rating 0.3 µm
• Maximum flow rate up to 1100 l/min (ANR, 0.7MPa)
• Connection size from 1/8'' to 3/4''
Documents
Product features
| Ablass manuell: | Ja |
|---|---|
| Ambient temperature max.: | 60 °C |
| Ambient temperature min.: | -5 °C |
| Anschluss: | G 1/4 |
| Betriebsdruck max.: | 1 MPa |
| Betriebsdruck min.: | 0.1 MPa |
| Connection: | G 1/4 |
| Druckluft: | Ja |
| Durchfluss max.: | 200 l/min |
| Filterfeinheit: | 0.3 µm |
| Filter fineness: | 0.3 µm |
| Filterschale aus Polycarbonat: | Ja |
| Flow rate max.: | 200 l/min |
| Media temperature max.: | 60 °C |
| Media temperature min.: | 5 °C |
| Medientemperatur max.: | 60 °C |
| Medientemperatur min.: | 5 °C |
| Operating pressure max.: | 1 MPa |
| Operating pressure min.: | 0.1 MPa |
| Series: | AFM#-D |
| Umgebungstemperatur max.: | 60 °C |
| Umgebungstemperatur min.: | -5 °C |
| compressed air: | yes |
| manual drain: | yes |
| polycarbonate bowl: | yes |
