CDQSB20-50D
Product number:
CDQSB20-50D
Product information "CDQSB20-50D"
• Round and compact design for easy and space-saving integration
• High force in a small body for demanding applications
• Reliable performance for precise lifting, lowering, and positioning tasks
• Versatile mounting options for easy adaptation to your application
• Robust construction for a long service life and reliable operation
Documents
Product features
| Ambient temperature max.: | 60 °C |
|---|---|
| Ambient temperature min.: | -10 °C |
| Anschluss: | M 5 |
| Betriebsdruck max.: | 1 MPa |
| Betriebsdruck min.: | 0.1 MPa |
| Connection: | M 5 |
| Dichtung: | NBR |
| Druckluft: | Ja |
| Druckluft gefiltert: | Ja |
| Gasket material: | NBR |
| Geschwindigkeit max.: | 0.5 m/s |
| Geschwindigkeit min.: | 0.05 m/s |
| Hub: | 50 mm |
| Kolbendurchmesser: | 20 mm |
| Kolbenstangengewinde: | M5 |
| Material: | Aluminiumlegierung |
| Media temperature max.: | 60 °C |
| Media temperature min.: | -10 °C |
| Medientemperatur max.: | 60 °C |
| Medientemperatur min.: | -10 °C |
| Operating pressure max.: | 1 MPa |
| Operating pressure min.: | 0.1 MPa |
| Piston diameter: | 20 mm |
| Piston rod thread: | M5 |
| Series: | CQS / CDQS |
| Speed max.: | 0.5 m/s |
| Speed min.: | 0.05 m/s |
| Stroke: | 50 mm |
| Umgebungstemperatur max.: | 60 °C |
| Umgebungstemperatur min.: | -10 °C |
| compact: | yes |
| compressed air: | yes |
| doppeltwirkend: | Ja |
| double acting: | yes |
| kompakt: | Ja |
| material: | aluminium alloy |
| mit Magnetring: | Ja |
| prefiltered: | yes |
| with magnet: | yes |
