IR3210-F04-A
Product number:
IR3210-F04-A
Product information "IR3210-F04-A"
• Zero bleed air – maximises efficiency.
• Up to 2× higher flow – swift response.
• Up to 27 % lighter – compact and easy to handle.
• Form-compatible with predecessors – seamless retrofitting.
• Flexible application – ideal for use between cylinder and solenoid valve.
Product features
| Ambient temperature max.: | 60 °C |
|---|---|
| Ambient temperature min.: | -5 °C |
| Anschluss: | G 1/2 |
| Betriebsdruck max.: | 1 MPa |
| Betriebsdruck min.: | 0.02 MPa |
| Connection: | G 1/2 |
| Druckeinstellbereich max.: | 0.4 MPa |
| Druckeinstellbereich min.: | 0.02 MPa |
| Druckluft: | Ja |
| Durchfluss max.: | 3500 l/min |
| Flow rate max.: | 3500 l/min |
| Manometeranschluss: | G1/8 |
| Media temperature max.: | 60 °C |
| Media temperature min.: | -10 °C |
| Medientemperatur max.: | 60 °C |
| Medientemperatur min.: | -10 °C |
| Operating pressure max.: | 1 MPa |
| Operating pressure min.: | 0.02 MPa |
| Pressure gauge connection: | G1/8 |
| Pressure setting range max.: | 0.4 MPa |
| Pressure setting range min.: | 0.02 MPa |
| Series: | IR1200/2200/3200-A |
| Umgebungstemperatur max.: | 60 °C |
| Umgebungstemperatur min.: | -5 °C |
| compressed air: | yes |
