JCDQ12-10
Product number:
JCDQ12-10
Product information "JCDQ12-10"
• Compact and lightweight square design for maximum space utilization
• High resistance to side loads
• Robust construction for a reliable and long service life
• Simple and flexible mounting options
• Ideal for clamping, ejecting, and lifting tasks in tight spaces
Documents
Product features
| Ambient temperature max.: | 60 °C |
|---|---|
| Ambient temperature min.: | 5 °C |
| Anschluss: | M 3 |
| Betriebsdruck max.: | 0.7 MPa |
| Betriebsdruck min.: | 0.07 MPa |
| Connection: | M 3 |
| Dichtung: | NBR |
| Gasket material: | NBR |
| Geschwindigkeit max.: | 0.5 m/s |
| Geschwindigkeit min.: | 0.05 m/s |
| Hub: | 10 mm |
| Kolbendurchmesser: | 12 mm |
| Kolbenstangengewinde: | M3 |
| Material: | Aluminiumlegierung |
| Media temperature max.: | 60 °C |
| Media temperature min.: | 5 °C |
| Medientemperatur max.: | 60 °C |
| Medientemperatur min.: | 5 °C |
| Operating pressure max.: | 0.7 MPa |
| Operating pressure min.: | 0.07 MPa |
| Piston diameter: | 12 mm |
| Piston rod thread: | M3 |
| Series: | JCQ / JCDQ |
| Speed max.: | 0.5 m/s |
| Speed min.: | 0.05 m/s |
| Stroke: | 10 mm |
| Umgebungstemperatur max.: | 60 °C |
| Umgebungstemperatur min.: | 5 °C |
| compact: | yes |
| doppeltwirkend: | Ja |
| double acting: | yes |
| kompakt: | Ja |
| material: | aluminium alloy |
| mit Magnetring: | Ja |
| with magnet: | yes |
