VM1000-4NU-01
Product number:
VM1000-4NU-01
Product information "VM1000-4NU-01"
• Minimal space requirements due to its compact and lightweight design
• High operational reliability thanks to the robust poppet valve construction
• Flexible application options with a wide variety of actuator styles such as roller levers or push buttons
• Easy integration into existing systems, ideal for use in machine tools and small industrial equipment
Product features
| 3/2 way: | yes |
|---|---|
| 3/2-Wege: | Ja |
| Ambient temperature max.: | 60 °C |
| Ambient temperature min.: | -10 °C |
| Anschluss: | Steckverbindung 4mm |
| Betriebsdruck max.: | 0.8 MPa |
| Connection: | Plug-in connection 4mm |
| Druckluft: | Ja |
| Druckluft gefiltert: | Ja |
| Durchfluss max.: | 54 l/min |
| Flow rate max.: | 54 l/min |
| Media temperature max.: | 60 °C |
| Media temperature min.: | -10 °C |
| Medientemperatur max.: | 60 °C |
| Medientemperatur min.: | -10 °C |
| N.C: | yes |
| N.C.: | Ja |
| Operating pressure max.: | 0.8 MPa |
| Series: | VM1000 |
| Umgebungstemperatur max.: | 60 °C |
| Umgebungstemperatur min.: | -10 °C |
| compressed air: | yes |
| mechanically operated: | yes |
| mechanisch betätigt: | Ja |
| prefiltered: | yes |
