ZH05BSA-06-F01
Product number:
ZH05BSA-06-F01
Product information "ZH05BSA-06-F01"
• One-touch fittings: Ø 6, 8, 10 and 12 mm. Screw-in connections: 1/8" to 1/2" (Rc/G).
• Nozzle diameters: 0.5, 0.7, 1, 1.3, 1.5, 1.8 and 2 mm
• Suction flow rate: up to 155 l/min
Documents
Product features
| Ambient temperature max.: | 50 °C |
|---|---|
| Ambient temperature min.: | -5 °C |
| Anschluss: | G 1/8, Steckverbindung 6mm |
| Betriebsdruck max.: | 0.6 MPa |
| Betriebsdruck min.: | 0.1 MPa |
| Connection: | G 1/8, Plug-in connection 6mm |
| Druckluft: | Ja |
| Düsendurchmesser: | 0.5 mm |
| Media temperature max.: | 50 °C |
| Media temperature min.: | -5 °C |
| Medientemperatur max.: | 50 °C |
| Medientemperatur min.: | -5 °C |
| Nozzle diameter: | 0.5 mm |
| Operating pressure max.: | 0.6 MPa |
| Operating pressure min.: | 0.1 MPa |
| Saugleistung max.: | 6 l/min |
| Series: | ZH-A |
| Suction power max.: | 6 l/min |
| Umgebungstemperatur max.: | 50 °C |
| Umgebungstemperatur min.: | -5 °C |
| Vacuum max.: | -89 kPa |
| Vakuum max.: | -89 kPa |
| compact: | yes |
| compressed air: | yes |
| kompakt: | Ja |
| mit Schalldämpfer: | Ja |
| with silencer: | yes |
